| Sensor |
Type: CMOS w primary colour filter and integrated Shake/Dust Reduction sensor movement system
Size: 23.5 x 15.6mm
Colour depth: 8 bits/channel JPG, 14 bits/channel RAW
Effective pixels: 23.35 MP
Total pixels: 24.71 MP
Recorded resolutions
Still: Jpeg –
L (24M:6016x4000),
M (14M: 4608x3072),
S (6M: 3072x2048),
XS (2M: 1920x1280)
RAW – L (24M:6016x4000)
Quality levels: ??? Best, ?? Better, ? Good, RAW (14-bit)
Movie (resolution/FPS):
Full HD (1920x1080, 60i/50i/30p/25p/24p)
HD (1280x720, 60p/50p/30p/25p/24p)
Dust Removal: DR II (ultrasonic vibration to low pass filter) with Dust Alert function |
| Lens |
Type/construction: PENTAX KAF2 bayonet stainless steel mount
Usable lenses: PENTAX KAF3, KAF2, KAF, and KA (K mount, 35mm screw mount, 645/67 med format lenses useable w adapter and/or restrictions)
SDM function: Yes
Power zoom function: Yes (power zoom only) |
| Focus System |
Type: SAFOX 11 TTL phase-matching - 27 point (25 cross type focus points in the centre)
Focus modes: AF Single (w focus lock, focus/shutter priority selectable), AF Continuous (w focus/FPS priority selectable), Manual
Focus point adjustment: Spot, Select, Expanded Area (S, M, L), Zone select, Auto (27 AF points) |
| Viewfinder |
Type: Pentaprism
Coverage (field of view): 100%
Magnification: 0.95X (w 50mm F1.4 at infinity)
Standard focusing screen: Natural-Bright-Matte III (interchangeable)
Diopter adjustment: -2.5m to 1.5m
Depth of field preview: Optical (diaphragm stop-down), Digital |
| LCD Monitor |
Type: 3.2” TFT colour LCD with brightness/saturation/colour adjustment AR coating and air-gapless glass.
Resolution: 1037K dots
Wide angle viewable: Yes |
| Flash |
Type: Retractable P-TTL popup flash
Guide number: 13m (ISO 100)
Coverage: 28mm wide angle (equiv. 35mm)
Flash modes: Auto, On, Redeye, Slow Sync, Slow Sync + Redeye, Trailing Curtain Sync, High-speed sync, Wireless, Manual
Flash exposure compensation: -2 to 1 EV (1/2 steps) |
| External Flash |
Type: Hotshoe (P-TTL), high speed sync and wireless w PENTAX dedicated flash, X-Sync Socket
Synchronization speed: 1/180 sec |
| Storage Media |
Internal memory: n/a
Removable memory: SD, SDHC, SDXC, EyeFi, FLU |
| Interfaces |
Ports: USB 3.0 hi-speed, AV out, HDMI out, DC in, cable switch, 3.5mm stereo microphone, X-sync socket
Video out: HD (via HDMI), NTSC, PAL
Printer interfaces: n/a |
| Power Supply |
Power source: Rechargeable Li-Ion battery D-LI90, D-BG5 Battery Grip (optional) with trays for 2nd D-Li90 battery or 6x AA batteries
Recordable images: Approx. 720 (approx. 560 w 50% flash, CIPA)
Playback time: Approx. 370 min
Movie recording time: Approx. 25 min (automatic overheat shutdown protection)
AC adapter available: Yes - (optional) K-AC132 |
| Physical Specs |
Body dimensions (W x H x D): 13cm x 10cm x 7.6cm
Body weight
Without battery or removable memory: 714.4g
Loaded and ready: 788.5g
Construction material(s): Magnesium alloy shell over metal chassis
Weather resistant: Yes (92 special sealing parts)
Operating temperature: -10 to 40°C |
| Language Support |
English, French, German, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish,
Polish, Czech, Hungarian, Turkish, Greek, Russian, Korean, Chinese
(Simplified/Traditional), Japanese |
| Image Stabilization |
Type: Sensor-Shift Shake Reduction with rotational compensation (3.5EV TBD)
Electronic level function: Yes, verification via viewfinder and LCD panel |
| Metering System |
Type: TTL open aperture metering using 86K pixel RGB sensor
Sensitivity range: EV -3 to 20 (ISO 100, 50mm F1.4)
Multi-Segment: Yes
Centre-weighted: Yes
Spot: Yes
Exposure compensation: +/- 5 EV (1/3 and 1/2 steps)
Exposure lock: Yes
Exposure bracketing: Yes (2, 3, or 5 frames, up to +/- 2 EV in 1/3 or 1/2 steps) |
| ISO Sensitivity |
Auto: ISO 100-51200 (1, 1/2, 1/3 steps), Auto ISO range selectable,
Bulb mode: Auto ISO n/a
Manual: 100-51200 (1, 1/2, 1/3 steps), |
| White Balance |
AUTO WB, Multi Auto WB,
Daylight, Shade, Cloudy, Fluorescent Light (D: Daylight Colour, N:Daylight White, W:Cool White, L:Warm White), Tungsten Light, Flash, CTE,
Manual mode(s): Yes, Manual WB (up to 3 settings), Colour Temperature Configuration (up to 3 settings), Copying the white balance setting of a captured image* WB fine adjustment available in all modes |
| Shutter |
Type: Electronically controlled, vertical-run, focal plane shutter
Shutter speed: 1/8000 to 30 sec (1/3 or 1/2 EV steps), Bulb |
| Capture Modes |
Mode selection: Green, Hyper Program (P), Sensitivity Priority (Sv), Shutter Priority (Tv), Aperture Priority (Av), Shutter & Aperture Priority (TAv), Metered Manual, Bulb, X-Speed, USER (3 presets).
Custom Image Modes: Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Bleach Bypass, Reversal Film, Monochrome, Cross Processing,
HDR: Auto, HDR1, HDR2, HDR3, Exposure Bracket Value adjustable, Automatic composition correction function
- All include gamut radar and fine adjustment of saturation, hue, high/low key, contrast, and sharpness (regular and fine adjustment scales). Monochrome mode includes adjustments for filter effects (green, yellow, orange, red, magenta, blue, cyan, infrared), toning (sepia, warm/cool), high/low key, contrast, and sharpness (regular, fine, and extra sharp adjustment scales).
Green simplified mode available: Yes
P/A/S/M/B: P, A, S, M, B (extended modes Sv, TAv)
Date stamp: n/a
Digital filters (capture): Extract Colour, Toy Camera, Retro, High Contrast, Shading, Invert Colour, Unicolor Bold, Bold Monochrome
Data record: Folder name (standard, date), file name (standard, customizable), embed copyright. |
| Drive Modes |
Mode selection: Single, Continuous (H,M,L), Self-Timer (12s, 2s), Remote (0s, 3s, continuous), Exp. Bracketing (standard, timer, remote), Mirror up (standard, remote), HDR Capture (3 shots at 1EV, 2EV, or 3EV, 3 blend settings plus Auto, pixel alignment)
Multi-exposure: Composite Mode (Additive/Average/Bright) Number of Shots (2 to 2000 images), Interval 2000 shots, 2 sec to 24 hrs, time delay available)
Continuous FPS (JPG ???)
- Continuous H: Approx. 8.3 FPS (60 JPG, 23 RAW)
- Continuous M: Approx. 4.5 FPS (100 JPG, 32 RAW)
- Continuous L: Approx. 3.0 FPS (200 JPG, 52 RAW)
Self-timer: Yes (12s, 2s)
Remote control: Yes, infrared (0s, 3s, continuous), cable switch |
| Playback Modes |
Mode selection: Single frame, multi-image display (6,12, 20, 35, 80 segmentation), display magnification (up to 16, 100% display and quick magnification available), rotating, histogram (Y histogram, RGB histogram), bright area warning, Auto Image Rotation, detailed info, Copyright Information (Photographer, Copyright holder), Folder Display, Calendar Filmstrip Display, Slide Show Mode pallet: Image Rotation, Digital Filter, Resize, Cropping, Slideshow, Save as Manual WB, RAW Development, Index Print, Protect, Movie Edit, Extract JPG from Movie, Magnification: up to 16X, scrollable, quick magnification.
Digital filters (playback): Base Parameter Adj, Extract Colour, Toy Camera, Retro, High Contrast, Shading, Invert Colour, Unicolor Bold, Bold Monochrome, Tone Expansion, Sketch, Water Colour, Pastel, Posterization, Miniature, Soft, Starburst, Fish-eye, Slim |
| File Formats |
Still: RAW (PEF, DNG), JPG (EXIF 2.30), DCF 2.0 compliant
Movie: MPEG-4 AVC/H.264(MOV) - JPEG(AVI) for internal movie record |
| Custom Functions |
Functions available: 27 |
| Computer Requirements |
*For device connectivity. Bundled software requirements may vary.
Windows: Windows 8 (32 bit/64 bit) / Windows 7 (32 bit/64 bit) / Windows Vista (32 bit/64 bit), Windows XP SP3 (32 bit)
Mac: Mac OS X 10.8 / 10.7 / 10.6 |
| Battery Life |
Power source: Rechargeable Li-Ion battery D-LI90, D-BG5 Battery Grip (optional) with trays for 2nd D-Li90 battery or 6x AA batteries
Recordable images: Approx. 720 (approx.. 560 w 50% flash, CIPA)
Playback time: Approx. 370 min
Movie recording time: Approx. 25 min (automatic overheat shutdown protection)
AC adapter available: Yes - (optional) K-AC132 |
| Dimensions |
13cm x 10cm x 7.6cm
|
| Weight |
Body weight
Without battery or removable memory: 714.4g
Loaded and ready: 788.5g |
| Operating Temperatures |
Operating temperature: -10 to 40°C |
| Operating Humidity |
Weather resistant: Yes (92 special sealing parts) |
