HIKMICRO Pocket2 Wi-Fi Thermal Imaging Camera

Name: HIKMICRO Pocket2 Wi-Fi Thermal Imaging Camera
Brand: HIKMICRO
SKU: HM-Pocket2
Price: 1271.99 NZD
Availability: InStock

SKU: HM-Pocket2

HIKMICRO Pocket2 Wi-Fi Thermal Imaging Camera-Jacobs Digital

Our Price

$1,271.99

incl. GST excl. GST

Shipping Quote

When will I receive it?

Request a price match

Have a question about this product?

Share

Print

About this product

POCKET SERIES

High performance compact thermal imaging camera for professionals.

Innovative Macro Mode

Using an extra clip-on macro lens and desk stand bracket, the Pocket2 thermal camera can see details as small as 100 microns stably and take accurate temperature readings on small objects, such as components on printed circuit boards or assemblies.

High Image Quality

A highly sensitive
Vox 256 x 192 (49,152 pixels) detector (NETD < 40 mK )
provides a distinct thermal image of the target.

Portable Pocket-sized Design

Easy to carry and hold. It fits perfectly in your pocket and tool bag

Rugged & Durable Design

IP54 rated for protection against water and dust.
Featuring 2-meter (6.6ft) drop protection,
suitable for industrial use.

3.5”LCD Touch Screen

View the details of your
target from
different angles on the large,
class-leading 3.5” LCD Touch Screen.

4 Image Modes / 7 Color palettes

Thermal, Fusion, PIP, and Optical modes to suit your preferred view
7 color palettes give different image display options

Faster Troubleshooting

Built-in speaker and flash light give the operator
audio and visual alerts to high temperatures.
Full-screen measurement using different user
presets checks everywhere instantly.

On-camera Recording

Built-in 16GB internal memory
provides onboard recording and playback.

Fast Communication

Connect (Wi-Fi or Hotspot) to HIKMICRO Viewer App
for transmitting pictures from camera to mobile phone.
Analyze, share images and generate reports in real-time on-site.

Multiple Level & Span Modes

Three Level & Span modes (manual, automatic,
and 1-Tap) help you instantly improve image
contrast and highlight potential problems.

Pocket2

IR Resolution

SuperIR

NETD

Image Frequency

Detector Pitch

Spectral Range

Focal Length

F-number

Field of View (FOV)

Spatial Resolution (IFOV)

Focus Mode

Min. Focus Distance

Image Display

Visual Camera

Display

Screen Brightness

Digital Zoom

Image Modes

Color Palettes

Measurement and Analysis

Object Temperature Range

Accuracy

Measurement Tools

Level and Span Mode

Data Storage and Communication

Storage Media

Image Storage Capacity

Annotations

Video Storage Capacity

Video File Format

Image File Format

Radiometric Infrared-Video Streaming (Compressed)

General

Wi-Fi

Bluetooth

USB Interface

LED Light

Battery Type

Battery Operating Time

Battery Charging Time

Power Saving Mode

Protection Level

Drop Test Height

Working Temperature Range

Storage Temperature Range

Relative Humidity

Weight

Dimension

Tripod Mounting

Power Supply

256 × 192 (49, 152 pixels)

Yes, on captured images and live view

40 mK (@ 25 °C, F#=1.0)

25 Hz

12 μm

7.5 to 14 μm

3.5 mm

F1.1

50° × 37.2°

3.43 mrad

Focus Free

0.3 m (0.98 ft)

3264 × 2448 (8 MP)

640 × 480 Resolution, 3.5" LCD Touch Screen with auto-rotation

Manual

1.0x to 4.0x continuous

Thermal/Visual/Fusion/PIP/Blending

White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red

-20°C to 400°C ( -4°F to 752°F )

Max (±2°C/3.6°F, ±2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F)

Center Spot, Hot Spot, Cold Spot

Auto/Manual/1-Tap Touch-screen

Built-in 16 GB flash memory (user available storage space is less than the nominal capacity)

Approx. 60,000 Images

Text note: max. 255 characters

Approx. 54 hours

MP4 video and Radiometric video

Radiometric JPEG

Over UVC

802.11 b/g/n (2.4 GHz and 5 GHz)

Bluetooth 4.2, supports wireless headsets

USB Type-C

Yes

Rechargeable Li-ion battery

Approx. 4 hours

Approx. 2.5 hours fully charged

Auto Power-off and manual sleep

IP54

2 m (6.56 ft)

-10°C to 50°C (-4°F to 122°F)

-20°C to 60°C (-4°F to 140°F)

< 95% non-condensing

Approx. 218 g (0.481 lb)

138.5 × 85.2 × 23.6 mm (5.45 × 3.35 × 0.93 in)

UNC ¼”-20

USB-C (5V/2A)
