About this product
Crystal clear vision
The EL Range redefines hunting equipment. This device combines the ability of razor-sharp first class optics with precise measuring functionality. High transmission, low weight and widest field of view in its class, literally setting new standards for optics and measuring precision.
Best observation performance without optical compromises
- High reproduction quality and transmission for bright and high-contrast images
- Wide-angle eyepiece for exceptionally large 60° field of view
- Maximum exit pupil distance (increased viewing comfort, especially for spectacle wearers)
- At 900 g the lightest in its class
Proven coatings, optimised for laser technology
- SWAROBRIGHT
- SWARODUR
- SWAROTOP
- SWAROCLEAN
Precise Measuring
A steady hand is needed to measure distant targets precisely. The legendary EL wrap-around grip, the low and perfectly balanced weight and unique shape ensure the EL Range’s good handling characteristics and the display of the exact distance to the desired target.
Intuitively operated technology
- Optimally placed measurement button, for immediate rangefinding readings
- Small cross hair allows precise measuring at long ranges
- Measuring range 30-1,370 m / 33-1,500 yds
- Range-finding accuracy ± 1 metre / 1yard above the entire measuring range
- Display intensity level can be fixed, or set for automatic adjustment according to ambient light levels
- Easy and intuitive menu navigation
Unparalleled ergonomics
- EL wrap-around grip for stable focusing on very small targets at long ranges
- Streamlined shape provides perfect stability allowing one-handed operation
Precise hit with SWAROAIM
Topographical conditions dictate the many challenges encountered during every day hunting. To take a precise shot up or down hill requires know-how & ballistic experience. Or a precision instrument. The EL Range with SWAROAIM, equipped with a radically new angle-shot programme developed by SWAROVSKI OPTIK, enables you to accurately ascertain the correct distance for a precise shot, even in the most difficult terrain.
Unique angle shooting program
Calculates the corrected trajectory of angled shots, based on a programme developed by SWAROVSKI OPTIK, taking into consideration the measured distance and angle to the target
- Scanning function available for angle measurement
- Optional indication for displaying the distance with the angle or with the corrected range
- Simply switch the SWAROAIM readout On or Off as required
- Irrespective of calibre
Technical Data for Swarovski EL RANGE 10X42 WB
|
Magnification
|
10x |
|
Effective objective lens diameter (mm)
|
42 |
|
Exit pupil diameter (mm)
|
4.2 |
|
Eye relief (mm)
|
|
|
Field of view (m/1000m)
|
110 |
|
Field of view (degrees)
|
6.3 |
|
Field of view, apparent (degrees)
|
61 |
|
Shortest focusing distance (m)
|
5 |
|
Dioptric compensation (dpt)
|
± 5 |
|
Diopter correction at ∞ (dpt)
|
|
|
Light transmission (%)
|
|
|
Interpupillary distance (mm)
|
56-74 |
|
Twilight factor
|
20.5 |
|
Length approx. (mm)*
|
160 |
|
Width approx. (mm)**
|
117 |
|
Height approx. (mm)**
|
81 |
|
Weight approx. (g)
|
895 |
Measuring
|
Measuring Range (m)
|
30 – 1370 |
|
Measuring Accuracy (m)
|
± 1 |
|
Measuring Time (sec)
|
≤ 1 |
|
Angular Measurement (degrees)
|
± 90 |
|
Laser
|
Class 1 EN/FDA |
|
Units
|
Yards / Meters |
|
Battery
|
CR2 |
|
Battery Life
|
1,000 measurements |
