Manfrotto 492 Centre Ball Head Camera Head

For all amateur photographers looking for a small and reliable head to perfectly match their compact camera or to support the ideal accessory to enrich the shot the MH492-BH is the head for taking it to the next level.

Multipurpose Tripod head made for compact system cameras
Easy locking and full pan and tilt movement
Strong enough to easily support up to 4kg
Features standard 9.5mm bottom attachment for versatility
¼" standard camera screw

Versatile, user-friendly, and made to last, this multi-purpose photographic head is made of highly resistant, lightweight aluminium so it is both portable and strong and it features a single ergonomic knob that controls both pan and tilt movements to be ready and fast in framing and shooting.
Complete with universal attachments such as a 6.35mm platform attachment and a 9.5mm female attachment at the base of the ball, you’ll be ready for anything. Compatible and practical, the MH492-BH simplifies any shoot.

Specifications

Weight: 0.14 kg
Base Diameter: 35 mm
Material: Aluminium
Front Tilt: -90° / +40°
Safety Payload Uni/Pdr 105:2021: 5 kg
Safety Payload Weight: 4 kg
Plate Type: fixed - with 1/4" screw
Colour: Black
Base Type: 22 mm
Ball Locking: Yes
Top Attachment: 1/4? screw
Easy Link: No
Friction Control: No
Head Type: Ball Head
Independent Pan Lock: no
Independent Tilt Lock: no
Lateral Tilt: -90° / +40°
Maximum Working Temperature: 70 °C
Minimum Working Temperature: -30 °C
Pan Bar Included: No
Pan Drag: NONE
Panoramic Rotation: 360 °
Quick Release: No
Tilt Drag: NONE
Working Height: 6.5 cm
