| Product Model |
A50PL |
| Max. Resolution |
4512 × 2512 (12 MP) |
| Frame Rate |
50 Hz (12 MP); 120 Hz (1080P) via firmware update before August 2026 |
| Lens (Focal Length) |
50 mm, F1.8 |
| Min. Focusing Distance |
3 m |
| Field of View |
7.2° × 4.0° / 12.6 m × 7.0 m @ 100 m |
| Magnification |
4.0× to 24.0× (continuous zoom in 0.1× steps) |
| Continuous Zoom Increment |
0.1× step value |
| Digital Zoom Ring Rotation |
Up to 120° |
| Detection Range |
Day: 1500 m |
| Light Pro |
Yes |
| Light Pro Description |
Light Pro algorithm improves low-light performance at dusk and night for clearer target recognition |
| Display |
1920 × 1080, 0.6-inch AMOLED |
| Image Modes |
Day, Night (B/W, Green, Yellow), Auto |
| Exit Pupil |
8 mm |
| Eye Relief |
55 mm |
| Diopter Range |
-5 D to +3 D |
| Video Recording |
On-board video recording |
| Record Video Resolution |
1920 × 1080 |
| Capture Snapshot |
Yes |
| Audio Recording |
Yes |
| PIP (Picture-in-Picture) |
Yes |
| Standby Mode |
Yes |
| Storage |
Built-in EMMC (64 GB) |
| Distance Measurement |
Yes |
| Recoil-activated Recording |
Yes |
| Freeze Zeroing |
Yes |
| Zeroing Profiles |
5 |
| Click Value |
1 click = 0.66 cm @ 100 m |
| Ballistic Calculation |
Yes |
| Max. Recoil |
1000 g / 0.4 ms |
| Mobile App Support |
HIKMICRO Sight App |
| Remote Access Requirement |
Remote Access must be enabled in the device menu before app connection |
| Wireless Connectivity |
Wi-Fi hotspot connection to smartphone |
| Hotspot Bands |
2.4 GHz and 5 GHz selectable |
| 5 GHz Use Note |
Recommended for short-range use within 5 m; use 2.4 GHz if the phone does not support 5 GHz |
| Hotspot Name |
HIKMICRO_Serial No. |
| Hotspot Password |
View in the Hotspot menu on the device |
| Connection Security |
Connection PIN code confirmation on device |
| Live View |
Yes |
| Remote Control via App |
Yes |
| Media Browsing & Saving |
Yes |
| Firmware Updates |
Yes |
| How-to Videos |
Supported through the app ecosystem |
| Repair Records & Warranty Inquiry |
Supported through the app ecosystem |
| Hotspot Auto-off |
Turns off if there is no connection for over 10 minutes |
| Battery Type |
Two internal rechargeable lithium-ion batteries + one replaceable/rechargeable external 18650 battery |
| External Battery Specification |
18650, 19 × 70 mm, 3.635 V, 3300 mAh |
| Built-in Battery Specification |
23 × 67 mm, 3.635 V, 3350 mAh |
| Battery Operating Time |
Up to 7 hours continuous running (@25°C, hotspot off, LRF on) |
| Power Supply Priority |
External battery first, then built-in battery |
| Power Input |
5 VDC / 2 A, USB Type-C |
| Charging Note |
USB Type-C charges the built-in battery only; use the supplied battery charger for the external battery |
| Charging Indicator Status |
Flashing red & green: error; solid red: charging; solid green: fully charged |
| Built-in Battery Charging Temperature |
0°C to 52°C |
| External Battery Charging Temperature |
0°C to 55°C |
| First Charge Recommendation |
Charge for more than 6.5 hours before first use |
| Laser Rangefinder |
Built-in |
| Laser Class |
Class 1 |
| Laser Wavelength |
905 nm |
| Max Measuring Range |
1200 m |
| Measurement Accuracy |
±1 m |
| Min Measuring Range |
3 m |
| Protection Level |
IP67 |
| Weight |
889 g (with external battery) |
| Dimensions |
442.8 × 83.5 × 90.5 mm |
| Mounting |
Standard 30 mm |
| Mount Ring Note |
Mounting ring needs to be purchased separately |
| Operating Temperature |
-30°C to 55°C (-22°F to 131°F) |
| IR Torch Support |
Supported via optional IR torch bracket; IR torch and bracket sold separately |
