HIKMICRO Gryphon GQ35L 640x512 Thermal Imager
Authorised Dealer
Our Price
$5,999
/
Outstanding Image Algorithm
Self-developed image algorithm optimizes image quality, bringing users a high-definition and cleaner picture, highlighting the edge of the object.
1.New Way to Control
The wheel is used for menu selection and zooming, making the operation more natural. Each rotation delivers an excellent sense of control to users.
2. Advanced VOx 12µm Imaging Sensor
The powerful VOx 12µm imaging sensor with NETD<35mK ensure the perfect distinction of the target and present clear and detailed pictures even in complete darkness.
3. Built-in Laser Rangefinder, Accurately Measure the Distance
The integrated laser rangefinder allows to determine the distance in various scenarios, which plays an important role in precision shooting.
4.Replaceable Battery
Two batteries and a HIKMICRO external battery charger are included in the package box, which gives the freedom to observe as long as needed even a full day.
| Sensor | VOx Uncooled Focal Plane Arrays |
|---|---|
| Sensor Resolution | 640x512 |
| Pixel Interval | 12 μm |
| NETD | <20mK |
| Magnification | 2.0x-16.0x |
| Digital Zoom | 1x, 2x, 4x, 8x |
| Aperture | 35mm |
| Field of View | 12.5°×10.0°/21.9m×17.5m@100m |
| Detection Range | 1800m |
| Battery Type | Replaceable and Rechargeable Li-ion Battery |
| Display Type | 1024 × 768, 0.39 inch, OLED |
| Storage Size | 16GB |
| Water Resistance | Yes |
| Working Temperature | -30°C to +55°C |
| Palettes | Black Hot, White Hot, Red Hot, Fusion |
| Battery Operating Time | 4.5 h (25 °C, with hotspot off) |
| Video Output | Digital Video |
| Dimensions (L x W x H) | 184.9 mm × 53 mm × 87.8 mm |
| Weight | 400g |
| IR Illuminator | No |
| Head Gear Adaptable | No |
