More on the wayOptical Performance
- 10x magnification for long-range identification
- Perger-Porro prism optical design combines the rich depth of field and limited internal reflective surfaces of a Porro prism light path with the more compact straight-line optical tube of a roof prism to minimize light loss and internal diffraction
- HDC (High Durable Coating) fully multicoated system has abrasion-resistant and anti-reflection properties to protect exterior lens surfaces and maximize light transmission with a natural neutral color fidelity and improved contrast
- Internal baffle system suppresses stray light for improved contrast
- Hydrophobic AquaDura coating on external optical surfaces allows dirt, dust, and fingerprints to be removed easily without leaving residue on the lens surfaces
- 345' field of view at 1000 yards
Laser Rangefinder
- Class 1 eye-safe infrared laser
- Range: 10 to 2500 yards
- Accuracy: 10-219 yards, ±0.5 yard; 219-438 yards, ±1 yard; 438 yards and beyond, ±0.5%
- Onboard sensors detect temperature, air pressure, angle for improved accuracy
- Spot mode for range to single subject; Scan mode for continuous measurement to multiple or moving targets
- Metering time averages 0.3 seconds
- Four-digit LED overlay with auto-brightness adjustment
- Displays distance in yards or meters
- Simple and intuitive two-button interface
- Runs on one included CR2 battery
ABC (Applied Ballistic Compensation) System
- Bluetooth connectivity to Leica Ballistic app for user-created ballistic profiles
- Applied Ballistics software displays all necessary correction information for shots out to 875 yards
- Can pair with Kestrel device for wind and weather info
- 12 pre-installed fixed ballistic curves based on the most popular round loads allow for easy ballistic drop compensation
Use and Handling
- Open-bridge/dual-hinge configuration reduces weight while providing a solid platform for the internal focusing system and rangefinder
- Slip-resistant center focus wheel is easy to use with high precision, even when wearing gloves
- ±4 dioptric correction on both eyepieces enables user to compensate for optical prescriptions for sharper views and ensure the in-view display information can be read
- Detachable 4-position click-stop rubber eyecups for use with or without eyewear
Construction Details
- Lightweight and strong magnesium alloy housing
- Slip-resistant and protective rubber armoring
- Nitrogen filled and O-ring sealed to be waterproof and submersible to 16.5', and resistant to internal fogging when moving through extreme changes in temperature or environmental conditions
- Measures 6.0 x 5.1 x 2.8", weighs 30.7 ounces
