Vixen Polarie U Star Tracker

SKU: VX35491

Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital
Vixen Polarie U Star Tracker - Jacobs Digital

Our Price

$1,204.35

$1,204.35

Green truck Usually Ships in 2-4 Weeks An order for this can be placed with our supplier, and usually ships within the specified timeframe.



Loading

10000

120435

Shipping calculated at checkout

When will I receive it?

About this product

The Polarie Star Tracker from Vixen Optics is an incredibly compact, motorized, tracking mount. The smooth and sleek, visually attractive Polarie attaches to a standard camera tripod with a ball head on one side and a DSLR or smaller camera on the other up to 7 pounds. Point the Polarie north with the integrated compass, use the alignment window by pointing it at Polaris, the North Star, or use an optional polar scope. Star trails and false fuzzies are eliminated in the time exposures of the attached camera as the Polarie tracks the motion of the stars across the celestial dome. Two user-supplied AA batteries can power the unit for ~4 hours or an optional external power supply (not included) can be used. Although, not waterproof, the Polarie is designed to function in most weather conditions. It weighs in at less than an incredible 1½ lbs and is about the size of a paperback book. This is one cool astrophotography star tracker.

Can support equipment weighing up to 7 lb (3.2kg)

Usable in both Northern and Southern hemispheres

Lightweight, compact with ~4 hours of tracking on 2 AA batteries (not included)

Simple polar alignment options allow camera movement in sync with the night sky

Tracking modes; Celestial tracking rate, 1/2 of the celestial tracking rate, Solar tracking rate (mean solar time) or Lunar tracking rate (mean lunar time)

The stepping pulse motor of the Polarie has an exceptionally precise movement utilizing a wheel gear of 57.6mm diameter aluminum alloy axis with a full-circle of 144-teeth. The worm gear has a 9mm diameter made from high tension brass and has 2-piece bearings.



Specifications

  • Payload Capacity ... 7 lb (3.2 kg)
  • Power Source ... 2 x AA batteries?DC2.4?3.0 V
  • Optional external power supply?DC4.4?5.25 V
  • Runtime ... ~4 hours at 68°F/20°C with a 3.3 lb / 1.5 kg load using alkaline batteries
  • Dimensions ... 5.4 x 3.7 x 2.3" / 137 x 95 x 58 mm
  • Weight ... 22.4 oz / 635.0 g without batteries
