Zeiss Conquest V4 4-16x44 #60 Elevation Turret Only

SKU: 522935-9960-080

Zeiss Conquest V4 4-16x44 #60 Elevation Turret Only
Zeiss Conquest V4 4-16x44 #60 Elevation Turret Only
Zeiss Conquest V4 4-16x44 #60 Elevation Turret Only
×

Zeiss Conquest V4 4-16x44 #60 Elevation Turret Only

SKU: 522935-9960-080


Have a question about this product?


Print this page

Our Price

or 12 months interest free

Gem

or 6 easy payments of $316.50

Laybuy

or 4 easy payments of $474.75

Afterpay

Loading

About this product

The Conquest V4 line of high-performance riflescopes combines the tried-and-true ZEISS optics concept with a rugged and functional design. Their compact design and perfect balance between a wide field of view and large magnification range is ideal for all types of hunting. The V4 models are equipped with a 4x zoom and functional, high-precision, and fully reliable mechanical components.

Special models have a ballistic turret with a wide reticle adjustment range (elevation and windage). As a result, the hunter has the flexibility needed for a variety of different hunting methods. Optional ballistic reticles are also available that allow the hunter to quickly make elevation and azimuth corrections with no mechanical adjustment necessary.

Thanks to its compact and lightweight design, the Conquest V4 4-16x44 is ideal for active hunting and hunting in the mountains. Its zoom range makes this V4 the perfect choice for medium and long-distance shots.

4x Zoom Range

The 4x zoom range allows hunters to perfectly recognize details and offers an excellent overall view for a safe and accurate shot.

A clear view, whatever the weather

There are always exciting things to be seen in the world of nature – even in wet weather. This is why ZEISS developed LotuTec®. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions.

Stable and Shot-Proof

The ZEISS V8, ZEISS Victory HT, ZEISS Conquest V6, and ZEISS Conquest V4 riflescopes are all ideally suited for use with "clip-on" attachments.

90% Light Transmission

Higher definition glass produces 90% to-the-eye light transmission, great low-light performance and excellent target resolution across the entire magnification range.

ZEISS T* Coating

ZEISS T* coating is a guarantee of the brilliant, high-contrast images­­ which you will experience above all in adverse light conditions and in the twilight. Behind it, however, there is no specific formula for building up the layers. Instead, it is a technology that is constantly adjusted to suit new glass materials and requirements, which varies from lens to lens.

Reticle Illumination

The reticle illumination can be adjusted finely and accurately over 10 different levels, allowing hunters to precisely adjust the brightness to any situation and time of day – for the perfect shot.

Performance

Magnification

4 – 16 x

Effective lens diameter

33.2 – 44 mm

Light transmission

90%

Exit pupil diameter

8.5 – 2.8 mm

Twilight factor

11.5 – 26.5

Field of view at 100 m (yds)

9.5 – 2.4 m (28 – 7 ft)

Objective viewing angle

5.4° – 1.4°

Diopter adjustment range

+ 2.0 | − 3.0 dpt

Eye relief

90 mm (3.54 ")

Parallax setting

9.1 m – ∞ (10 yds – ∞)

Adjustment range at 100 m

230 × 175 cm

Adjustment per click at 100 m

1/4 MoA (0.7 cm /100 m)

Centre tube diameter

30 mm

Eyepiece tube diameter

44 mm

Objective tube diameter

50 mm

Features

LotuTec | Nitrogen filled

+ | +

Water resistance

400 mbar


Physical

Operating temperature

− 25°C | + 50°C (− 13°F | + 122°F)

Length

356 mm (14.0 ")

Weight (without inner rail)

640 g (22.6 oz)

Weight (with inner rail)

-
