Zeiss Conquest V4 4-16x44 #64 Elevation Turret Only Zmoai-t 30 Rifle Scope

About this product

The Conquest V4 line of high-performance riflescopes combines the tried-and-true ZEISS optics concept with a rugged and functional design. Their compact design and perfect balance between a wide field of view and large magnification range is ideal for all types of hunting. The V4 models are equipped with a 4x zoom and functional, high-precision, and fully reliable mechanical components.

Special models have a ballistic turret with a wide reticle adjustment range (elevation and windage). As a result, the hunter has the flexibility needed for a variety of different hunting methods. Optional ballistic reticles are also available that allow the hunter to quickly make elevation and azimuth corrections with no mechanical adjustment necessary.

Thanks to its compact and lightweight design, the Conquest V4 4-16x44 is ideal for active hunting and hunting in the mountains. Its zoom range makes this V4 the perfect choice for medium and long-distance shots.

ZEISS CONQUEST V4 4-16×44 SECOND FOCAL PLANE WITH ILLUMINATED RETICLE ZMOAI-T 30 #64, ELEVATION TURRET ONLY

The balance between its wide field of view and magnification range make this compact riflescope ideal for all types of hunting.

Uncompromising quality and ruggedness – the Conquest® V4 line of high-performance riflescopes combines the tried-and-true ZEISS optics concept with a rugged and functional design. Equipped with 4x zoom and functional and fully reliable mechanics, these scopes set a new standard in their class.

Thanks to its well-balanced zoom range, this compact riflescope is the perfect all-rounder for medium-range and long-distance shots.

This scope is suitable for hunting from a blind both at dusk and at night. Thanks to the large-diameter lens and illuminated reticle, high accuracy is guaranteed – even in low light conditions.

ZMOAI-T 30 RETICLE

The thin lines are distinctive and cover the least amount of target possible, all
while remaining highly effective for field shooting use and open terrain hunting
applications. Each hash mark represents one MOA spacing, and MOA references
are easily identified with even MOA numbers illustrated adjacent to the main
horizontal and vertical lines of the reticle. The floating center point of aim
allows for ultra-precise shot placement. The floating dots located left and right
of the main vertical centerline allow the shooter to validate windage calls and
bullet impact without guesswork. This strongly supports fast follow-up shots
for corrected windage holds. The MOA reference marks and indicators subtend
accurately at the riflescope’s highest magnification setting.
The designation of “T20” and “T30” represents the MOA hash marks available
below the horizontal centerline of the main reticle.

The world’s finest illuminated dot

ZEISS T* Coating

ZEISS T* coating is a guarantee of the brilliant, high-contrast images­­ which you will experience above all in adverse light conditions and in the twilight. Behind it, however, there is no specific formula for building up the layers. Instead, it is a technology that is constantly adjusted to suit new glass materials and requirements, which varies from lens to lens.





A clear view, whatever the weather

There are always exciting things to be seen in the world of nature – even in wet weather. This is why ZEISS developed LotuTec®. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions.

Confidence in toughest conditions.

ZEISS have put their optics through rigorous stress testing, anywhere from continuous shocks, extreme and rapid temperature deviations through to water proofing.

PERFORMANCE

Magnification	4 – 16 x
Effective lens diameter	33.2 – 44 mm
Exit pupil diameter	8.5 – 2.8 mm
Twilight factor	11.5 – 26.5
Field of view	9.5 – 2.4 m (31 – 8 ft)
Angular field of view, real	5.4° – 1.4°
Diopter range	+ 2.0 | − 3.0 dpt
Eye relief	90 mm (3.54 “)
Parallax setting	45.7 m – ∞ (50 yds – ∞)
Adjustment range at 100 m	230 × 175 cm
Adjustment per click at 100 m	1/4 MoA (0.7 cm /100 m)
Centre tube diameter	30 mm
Eyepiece tube diameter	44 mm
Lens tube diameter	50 mm

FEATURES

LotuTec | Nitrogen filled	+ | +
Water resistance	400 mbar

PHYSICAL

Operating temperature	− 25°C | + 50°C (− 13°F | + 122°F)
Length	356 mm (14.0 “)
Weight (without inner rail)	640 g (22.6 oz)
Weight (with inner rail)	–
