Minelab Vanquish 560 Pro Pack Metal Detector
Authorised Dealer
Our Price
$1,019
/
Frequently bought with
The VANQUISH® 560 PRO-PACK is the ultimate packout for professional-level performance in a simplified, intuitive design. Powered by Minelab's proven Multi-IQ® technology, it scans across multiple frequencies at once for reliable target identification and faster target recovery in changing ground.
With 30 discrimination segments, four levels of Iron Bias control and five audio tones, this detector makes it easy to separate trash from treasure. The VANQUISH 560 PRO-PACK includes both the V12X and V8X coils, providing options for wide coverage or precision in tighter ground. Fully waterproof up to 5 m (16 ft) with an IP68 rating, it's made to perform on beaches, lakes and wet terrain.
A red LED monochrome display keeps visibility high in low light, while ML60 wireless earbuds with Bluetooth® LE Audio and handgrip vibration deliver rapid, uninterrupted signal feedback. Lightweight, compact and built to detect longer with up to 10 hours of battery life.
Highlights
Proven Performance
Multi‑IQ powers performance across all soils, all the time.
See in Any Light
Detect in low‑light conditions with a red LED display and built‑in flashlight.
Intuitive Interface
Streamlined controls for simple navigation and seamless operation.
Advanced Feedback
Detect hands‑free with the ML60 wireless earbuds.
Search Modes
With Park, Field, Beach and a customisable User Profile, your detector is ready for any ground you explore. These modes let you adapt seamlessly to busy sites, wide fields or challenging shorelines, while the User Profile gives you quick access to your own preferred settings. Together, they deliver the versatility to hunt effectively in almost any environment.
Fully Waterproof
With an IP68 rating, this detector is built to handle water, dirt and dust with no compromise to performance. Fully submersible up to 5 m (16 ft), it’s engineered for versatility across submerged environments, wet terrain and unpredictable weather. Reliable detection continues uninterrupted in creeks, shorelines, rain-soaked ground and other demanding conditions.
10 volume levels for both overall volume and ferrous tone response, while five distinct target tones give greater control over how signals are heard. Volume can be adjusted to suit any environment, while target tones provide sharper audio separation. These features work together to support faster recognition and more intuitive detecting in the field.
10 Sensitivity levels and 30 Discrimination Segments provide advanced control over how the detector responds to both ground conditions and metal targets. Adjust sensitivity to detect faint signals or stabilise performance in difficult soils, while discrimination allows for isolation of desired metals. Working in tandem, these features deliver the precision and control needed to maximise every hunt.
Four Iron Bias levels give you control over how iron signals are handled, improving clarity in trash-filled ground and helping valuable targets stand out.
Multi-IQ Technology
Why Multi-IQ? Because more performance shouldn’t mean more effort. Minelab’s proven simultaneous multiple frequency technology gives you the power of multiple detectors working for you at the same time.
With Multi-IQ there's no switching frequencies, no second-guessing. Just turn it on and start finding. Coins, gold, jewellery. Parks, fields, beaches. No terrain's off-limits. No treasure left behind.
All metals. All soils. All the time.
More Features
Included Coil
Detect your way with the V12X 12" × 9" Double‑D coil for depth and the V8X 8" × 5" Double‑D coil for precision.
Rechargeable Battery
A built‑in lithium‑ion rechargeable battery delivers dependable performance, with up to 10 hours of continuous run time.
Pinpoint Mode
Included Pinpoint Mode to help you zero‑in on targets and dig smaller holes with extreme precision.
3-Year Warranty
Built to last and protected by a 3‑year warranty.
 MULTI-IQ With Minelab’s proven Multi-IQ technology, you get the combined performance of multiple detectors in one, all working together at the same time. Just turn it on and start detecting. |  WATERPROOF IP68-rated for full submersion up to 5 m (16 ft), allowing you to detect in oceans, rivers or heavy rain without hesitation. |
 LIGHTER SWING Weighing just 1.26 kg (2.8 lbs), the sleek aluminium and fibreglass S-bend shaft is collapsible, ergonomic and built to travel. |  BATTERY A built-in Lithium-ion battery keeps you hunting longer with up to 10 hours of battery life. No spares required. |
 COIL The V12X 12" Double-D coil comes included as standard. |  DISCRIMINATION LEVEL Quickly distinguish treasure from junk with 30 discrimination segments, 119 Target IDs and four levels of Iron Bias control. |
 COMPACT AND READY Lighter Swing: Weighing just 1.26 kg (2.8 lbs), the sleek aluminium and fibreglass S-bend shaft is collapsible, ergonomic and built to travel. |  TARGET TONES CONTROL 10 levels for both overall volume and ferrous tone response, plus five target tones provide clear audio control, making it easier to distinguish targets with greater precision. |
 PINPOINT MODE Included Pinpoint mode to help you zero-in on targets with extreme precision. | |
| Minelab VANQUISH 560 PRO‑PACK — Specifications | |
|---|---|
| Search Modes | |
| Search Modes | Beach, Park, Field, User Profile |
| Custom User Search Profile | Yes |
| Pinpoint | Yes |
| Detection Controls | |
| Operation Frequency | Multi‑IQ® (Simultaneous Multi‑Frequency) |
| Sensitivity | 10 Levels |
| Noise Cancel | Auto |
| Audio Features | |
| Wireless Audio | Bluetooth LE Audio (LC3 Codec) |
| Volume Control | 10 Levels |
| Ferrous Volume | 10 Levels |
| Target Tones | 5 Tones |
| Included Headphones | ML60 Wireless Earbuds |
| Audio Output Options | Built‑in Loudspeaker, 3.5 mm (1/8") Wired Headphones, Bluetooth LE Audio |
| Discrimination | |
| Discrimination Segments | 30 Segments |
| Target IDs | Ferrous: −19 to 0 | Non‑Ferrous: 1 to 99 |
| Depth Indicator | 5 Levels |
| Iron Bias | 4 Levels |
| Physical & Environmental | |
| Length | Collapsed: 79 cm (31") | Extended: 142 cm (56") |
| Weight | 1.26 kg (2.6 lb) |
| Operating Temperature | −10 °C to +40 °C (14 °F to 104 °F) |
| Storage Temperature | −20 °C to +70 °C (−4 °F to 158 °F) |
| Waterproof Rating | IP68 — submersible to 5 m (16 ft) |
| Additional Features | |
| Display | Monochrome LCD |
| Display Backlight | Yes |
| Keypad Backlight | Yes |
| Flashlight | Yes |
| Vibration | Yes (handgrip vibration) |
| Key Technologies | Multi‑IQ, Bluetooth LE Audio (LC3) |
| Power & Warranty | |
| Battery Type | Internal Lithium‑Ion Rechargeable |
| Battery Life | Up to 10 hours (typical) |
| Warranty | 3 Years (Control Box & Coil) |
| What’s in the Box (Pro‑Pack) | |
| Standard Coil | V12X 12" × 9" Double‑D Elliptical |
| Additional Coil | V8X 8" × 5" Double‑D Elliptical |
| Included Earbuds | ML60 Bluetooth LE (LC3) Wireless Earbuds |
| Accessories | Magnetic USB‑C Charge Cable (typical), Quick Start / Getting Started Guide |
