SkyWatcher 80/600 Black Diamond ED Doublet Refractor OTA Telescope
SKU: SWBDED80-OTA
Click the image to enlarge
SkyWatcher 80/600 Black Diamond ED Doublet Refractor OTA Telescope
SKU: SWBDED80-OTA
Pickups and Delivery
In-store pickup
We don't have this item in our store right now. Please enquire for availability.
If you come to pick up your order please bring photo ID, if someone else is picking it up on your behalf please contact us prior to pickup.
Delivery estimates
Once your order has been picked up by the courier please allow 2 working days for North Island addresses, for the South Island allow 3 working days. Rural deliveries and extra-large items may take several additional days.
Shipping costs
Shipping costs are automatically calculated during checkout. The price of shipping varies based on the delivery location. Select items may be be eligible for free shipping.
Delivery of oversize items
Oversize items such as very large telescopes may only be available via pickup from a depot or a business address. For a list of available depots, click here
Security
To ensure the safe delivery of your order we require a signature with all parcels. Some exceptions may be made if you give the courier company authority to leave parcels at your preferred address.
About this product
The Sky-Watcher 80/600 Black Diamond ED Doublet RefractorOTAis a refractor telescope that well designed for wide-field astronomical observation of prominent nebulae, star clusters, and galaxies from a dark-sky location. Come with focal ratio f/7.5, it can be used as an astrograph for sky photography or telephoto lens. The Ultra high contrast of this Sky-Watcher ED Refractor allows the subtlest of details to be easily scrutinized under conditions of good seeing.
Metallic High-Transmission Lens Coatings (MHC)
Each air-to-glass lens surface has been coated by Sky-Watchers proprietary MHC. An anti-reflection metallic coatings which ensure optimum light-transmission approaching 99.5%.
Light-Baffled Optical Systems
The objective lens cell of this 80/600 Black Diamond ED Doublet OTAis light-baffled to reduce stray & unfocused light to insure optimum contrast. The interior of the tube is flat blackened to prevent unfocused internal light reflections from reaching the focal plane.
Precision 2 Crayford Focuser
This precision 2 Crayford Focuser is mechanically ultra-smooth and backlash-free, offers you a fine and ultra-fine focusing adjustments.
Tube Materials
The optical tube material is rolled steel, powder-coated reflective gloss black with gold fleck accent. The front and back cells are cast-aluminum painted white & black.
Telescope Tube Attachment Hardware
The optical tube comes with attachment hardware that allows it to be securely fastened to any Sky-Watcher Mount. The quick-release tube rings provided with Black Diamond ED80 are cast-aluminum, painted white.
In the Box:
- ED80 OTA
- 2 Diagonal
- 1.25 Focuser Adaptor
- 850 Finderscope with Bracket
- Eyepiece LET 28mm
- Tube Ring Attachment to Any Sky-Watcher Mount
- Piggyback Bracket
| Optical Design | ED Refractor OTA |
| Model Number | SWBDED80-OTA |
| Aperture | 80mm |
| Focal Length | 600mm |
| Eyepieces | LET28mm |
| Focuser Diameter | 2 |
| Finder Scope | 9x 50mm |
| Diagonal | 2 90§ Dielectric Diagaonal |
| Highest Practical Power | 160x |
| Recommended Usage | Advanced Users |
| Tube Dimensions | 10cm x 62cm |
| Shipping Weight | 8.5kg |
