Zeiss Digital Thermal Imaging DTI 3/35

SKU: ZEDT-527010

Zeiss Digital Thermal Imaging DTI 3/35
×

Zeiss Digital Thermal Imaging DTI 3/35

SKU: ZEDT-527010


When will I receive it?

Have a question about this product?


Print this page

Our Price

or 12 months interest free

Gem

or 6 easy payments of $1,033.16

Laybuy

or 4 easy payments of $1,549.75

Afterpay

Loading

Green truck Usually ships in 2-3 days

About this product

Designed to be easy to use in the dark, the DTI 3/35 Digital Thermal Imaging Camera from ZEISS will help you find your targets when hunting or observing wildlife. The monocular-style camera has a range of 1350 yards, with 2.5x optical magnification, and 4x digital zoom in 0.5x steps, for precise target identification. The imagery is displayed on a 1280 x 960 LCOS display with your choice of four color palettes: black hot, white hot, red hot, and rainbow. You can use the Picture-in-Picture function to see a zoomed overlay on the original scene, which is helpful if your target makes sudden movements. The Hot Tracking mode puts a red box around the warmest source in your image, making it easier to find heat sources in densely overgrown areas.

The DTI 3/35 records up to 15GB of photos and video, but you can also livestream or share data to your phone via the ZEISS Hunting App. The camera is equally easy to use with either hand, and is designed for your fingers to fall naturally onto the power, shutter, zoom, and menu buttons. The carry strap has two connection points, so it can be lowered naturally and quietly when it's time to reach for your rifle. Powered by a built-in Li-ion rechargeable battery, the camera has a runtime of seven hours. It measures 7.6" long and weighs 15.8 ounces.

Optical Performance

  • 2.5x optical magnification, 4x digital zoom in 0.5x steps magnification
  • 35mm focal length, 62' linear field of view at 100 yards

Digital Night Vision

  • 384 x 288 sensor, 17-micron pitch
  • Maximum viewing range 1350 yards
  • 1280 x 960 LCOS display
  • Picture-in-Picture overlays zoomed view on original view
  • Hot Tracking shows warmest spot with red box—good for searching densely vegetated areas
  • Choose red hot, black hot, white hot, or rainbow palette

Photo/Video Capabilities

  • 384 x 288 photo and video resolution
  • Share or stream photos and video via ZEISS Hunting app
  • 15GB onboard storage

Use and Handling

  • Ambidextrous, ergonomic controls
  • Built-in rechargeable Li-ion battery, 7 hours runtime per charge
  • IP66-rated water resistance
  • Measures 7.6 x 2.6 x 2.4", weighs 15.9 ounces

Specs:

General:
Configuration Monocular
Sensor Size 384 x 288
Display 1280 x 960
Refresh Rate 50 Hz
Pixel Size 17 µm
Thermal Sensitivity
Detection Range 1350 yd / 1234.4 m
Performance:
Magnification 2.5x
Lens System 35 mm, f/1.0
Angle of View 11.7 x 8°
Camera:
Storage 15 GB via Built-In Memory
Connectivity:
Wi-Fi 802.11b/g
Bluetooth None
Connections 1 x USB Type-C
Power & Environmental:
Battery 1 x Rechargeable Lithium-Ion (Approx. 7 Hours)
Operating Temperature 14 to 122°F / -10 to 50°C
Physical:
Water Resistance IP66
Dimensions 7.6 x 2.6 x 2.4" / 19.3 x 6.5 x 6 cm
Weight 15.9 oz / 450.0 g
